    Automatic Retractable Endoscopic High-temperature Resistant Thermal lmaging Camera

    Ask Lasest Price
    Brand Name : KAIDUN
    Model Number : KDG016
    Payment Terms : T/T
    Supply Ability : 5000 units/year
    Delivery Time : 5-8 week
    • Product Details
    • Company Profile

    Automatic Retractable Endoscopic High-temperature Resistant Thermal lmaging Camera

    Cylinder-type High-temperature In-furnace Camera
    Key Features
    • The KDG016 is a High-temperature Camera Equipped with an Air-cooled housing
    • The camera lens of this system equipment can be directly extended to the observation hole on the furnace wall to monitor the operation of workpieces inside the furnace, as well as the conditions of materials, flame shape,and other related situations.
    Application Environment

    Metallurgical & Steel Industry


    Power Generation Industry


    Petrochemical & Chemical Industry


    Glass & Ceramic Industry


    Waste Incineration & Environmental Protection

    High-temperature resistant cameras are engineered to operate reliably in extreme thermal environments (typically -40°C to 1200°C, depending on models) where standard cameras fail due to overheating, component degradation, or structural damage.
    Main Features
    Material304 Stainless Steel + Local High-temperature Resistant Pot
    Operating ConditionsTemperature inside the furnace ≤ 1500℃ /2000℃ Customizable
    Dust Concentration in
    the Operating Environment
    ≤ 200 mg/m3 (based on cement dust as the standard)
    VideoIP
    Thermal Resolution384*288 / 640*512 optional
    Thermal Museurement Range0°C to 400°C/400°C to 1500°C
    Thermal Museurement Accuracy±3°C@(0°C~100°C) / ±2℃ or ±2% of the reading (whichever is larger).
    Comperssed Air Pressure0.2~0.4Mpa
    Compressed Air Flow Rate0.3~0.7m³/min(0.7 m³/min at an air pressure of 0.4 MPa)
    Thermal Museurement ToolsArbitrary Fixed Point, Full-Screen High / Low Temperature Capture, Central Point Temperature Measurement Line/Area Analysis Tool, Manual Temperature Range Selection, Radar Temperature Measurement Tool
    Interface ProtocolsONVIF,GB28181,ModbusTCP(supports transmission of regional temperature information)
    VoltageDC12V/AC220V optional
    Dimensions950*398*210mm
    Weight≤25kg
    MountingWeld together with the matching mounting base plate to the reserved hole of the furnace.
    Dimensions
    Automatic Retractable Endoscopic High-temperature Resistant Thermal lmaging Camera
